Micromechanical recovery of waste cement via efficient rehydration under the effect of Tris(2-hydroxyethyl) amine-Graphene Oxide


Cement is the most used material in buildings and structural constructions thanks to its cost-effective, availability and efficiency. Considering the current trends, the demand for cement materials is expected to increase due to the increase in population and demand for infrastructure. Unfortunately, the resulting construction wastes have led to environmental degradation going against the current global policies about environment protection.

To this note, efficient techniques for minimizing the wastes resulting from cement as well as associated effects is highly desired. Recent studies have shown that recycling will be the best alternative. For instance, different approaches including using cement wastes as inert aggregates in concrete pore filling and using recycled cement aggregate to manufacture concrete products have been developed.

However, regardless of the great improvements in using the waste cement, mechanical recovery of the hydrated cement is still missing. Therefore, researchers have been looking for alternatives and have identified the use of modified graphene as a promising solution due to its capability of improving the durability and mechanical properties of the concretes. However, the effects of graphene oxide on the recovery of waste cement are yet to be fully explored.

To this end, Tianjin University scientists: Dr. Miaomiao Hu, Professor Jintang Guo, Mr. Pengpeng Li, Miss Jinjie Fan and Professor Yakai Feng from the Department of Polymer Science and Engineering investigated the recovery of cement through rehydration process. In particular, a Tris(2-hydroxyethyl) amine-Graphene Oxide was fabricated to enable micro- mechanical recovery of waste cement in the presence of sodium silicate. They improved the micromechanical properties and refined the microstructure of waste cement. Their work is currently published in the research journal, Construction and Building Materials.

Briefly, the experimental work involved reacting the Tris(2-hydroxyethyl) amine-Graphene Oxide with the resulting products of the activities of the carboxylic and epoxy groups on the graphene oxides. Next, several techniques including X-ray diffraction, Raman spectra, and atomic force microscope were utilized to characterize the rehydrated sample. Eventually, the mechanical properties of the recycled cement were improved by quickly and efficiently extracting the solid calcium during the rehydration process.

The authors observed that rehydrated cement exhibited an increase in mechanical properties. This was attributed to the transformation of the CH to the C-S-H gel in sodium silicate due to the fast extraction of calcium from the hydrated cement. Consequently, a decrease in the pore size of the rehydrated cement was noted due to the addition of the Tris(2-hydroxyethyl) amine-Graphene Oxide. Furthermore, it was worth noting that the properties of the recycled cement depended majorly on the structural elements and more so at the micro- and nanoscale.

In summary, Tianjin University scientists successfully investigated the effects of graphene oxide on the recovery of waste cement. In general, positive results have been obtained including improved mechanical properties of the rehydrated cement indicates that graphene oxide is an excellent tool in the mechanical recovery of waste cement. Therefore, the study will reduce the associated environmental impact of the cement wastes as well as pave way for future advancement in recycling cement wastes.

Micromechanical recovery of waste cement via efficient rehydration under the effect of Tris(2-hydroxyethyl) amine-Graphene Oxide- Advances in Engineering

About the author

Jintang Guo is a Professor of School of Chemical Engineering and Technology in Tianjin university, China. She received her Ph.D. degrees at Tianjin university in 1998. She has published more than 90 research papers on journals and academic conferences and obtained more than 30 national invention patents. In addition, she has also undertaken scientific research projects from the National Natural Science Foundation, and the project cooperated with some enterprises such as CNPC Engineering technology R&D company limited, China National Offshore Oil Corporation.

Her current research focus on chemical additives applied in oil field chemicals, polymer additives for oil-well cementing, functional polymers and disinfectant.

About the author

Miaomiao Hu is a Ph D student at School of Chemical Engineering and Technology in Tianjin university (Tianjin; China). She received her B.S. in applied chemistry (2013) from Shaanxi University of Science & Technology (Xi’an; China). Her research interests include self-healing cement, recovery and recycle of waste cement, green reinforcements for cement.



Hu, M., Guo, J., Li, P., Fan, J., & Feng, Y. (2018). Micromechanical recovery of waste cement via efficient rehydration under the effect of Tris(2-hydroxyethyl) amine-Graphene Oxide (TEA-GO). Construction and Building Materials, 188, 470-479.

Go To Construction and Building Materials
