Solution combustion synthesis of highly dispersible and dispersed iridium oxide as an anode catalyst in PEM water electrolysis

Significance Statement

Hydrogen is a chemical energy carrier alternative to fossil fuels. It has the capacity to offer affordable, clean and reliable energy supply to satisfy growing global demands. Besides being a clean fuel producing water as the only by-product, hydrogen can be synthesized implementing renewable and natural energies and then it can be implemented in fuel cells to generate clean power for a number of applications.

Electric potential induced water splitting appears to be a promising method for the synthesis of highly pure hydrogen. Two main reactions take place in the electrochemical water splitting. These are oxygen evolution reaction and hydrogen evolution reaction, where oxygen evolution reaction is more energy demanding as compared to the latter. Oxygen evolution reaction is, therefore, the main contributor to energy losses owing to higher over-potential of the oxygen evolution reaction in water electrolysis.

Iridium-based materials are important catalysts for polymer electrolyte membrane water electrolysis owing to their unmatched stability as well as performance in the acidic environment of typical polymer electrolyte membranes. Unfortunately, their high cost restricts their large-scale implementation in industrial applications. Therefore, for improving their utilization, identifying a synthesis approach of nano-structured iridium oxide with an active surface area would play a pivotal role.

Muralidhar Chourashiya and Atsushi Urakawa at the Institute of Chemical Reseaerch of Catalonia (ICIQ) developed a one-step cost-effective solution combustion synthesis method to produce nano-structured iridium oxide and iridium oxide-based materials ideal for polymer electrolyte membrane electrolysis. Their work is published in Journals of Materials Chemistry A.

The authors applied iridium chloride as the sole source of iridium owing to the scarcity of its nitrates and thereafter adopted the solution combustion synthesis approach. They prepared phase-pure and nanostructured iridium oxide materials using excess of glycine, as a combustion fuel, and through the incorporation of an oxidizing additive. They also evaluated the effects of precursor solution composition on the structural attributes of the resulting iridium oxide as well as iridium oxide-based materials.

The researchers consequently incorporated these materials as anode catalysts into membrane electrode assemblies, evaluated their polymer electrolyte membrane water electrolysis performance, and compared the results with those of commercial membrane electrode assemblies in which IrRuO was applied as the anode catalyst.

Chourashiya and Urakawa were able to obtain phase-pure iridium oxide in supported and unsupported forms by varying the preparative parameters in solution combustion synthesis and the kind of nitrate (i.e. the oxidizing) additive. They were also able to obtain nano-crystallites of iridium oxide in the range of 3.5nm-12nm nanoparticles through the solution combustion synthesis.

Iridium oxide incorporated and dispersed in amorphous alumina indicated a high surface area of 131m2/g and 1.78A/cm2 current density at 1.8V. This was comparable to the performance of state-of-the-art commercial membrane electrode made of IrRuOx under polymer electrolyte membrane water electrolysis.

The dispersion of the material in the catalyst ink applied for the synthesis of the membrane electrode assembly was superior to that of commercial iridium oxide nanoparticles and the amount of precious metal in the catalyst made by solution combustion synthesis could be attained by 45%wt as opposed to that in the commercial membrane electrode assembly.

Solution combustion synthesis of highly dispersible and dispersed iridium oxide as an anode catalyst in PEM water electrolysis- Advances in Engineering

About the author

Atsushi Urakawa was educated in an international environment and obtained BSc in Applied Chemistry at Kyushu University (Japan) with one year stay in the USA, MSc in Chemical Engineering at Delft University of Technology (The Netherlands) and PhD in Natural Science at ETH Zürich (Switzerland). In 2006, he undertook a position as Senior Scientist/Lecturer at ETH Zürich. Since January 2010, he has joined Institute of Chemical Research of Catalonia (ICIQ) as Group Leader with particular research emphasis on the development of heterogeneous catalysts and processes particularly on CO2 conversion catalysis. Based on rational understanding aided by in situ and operando spectroscopic methods, he aims at accelerated tech transfer of innovative catalytic technologies to industry.

About the author

Muralidhar Chourashiya is from Maharashtra, India and has received his Master’s (May 2005) and Ph.D. degree (April 2010) in Physics (materials for fuel cell technology) from Shivaji University, India. After his doctorate, he joined Electrochemistry Lab of Department of Materials Science and Engineering at Chonnam National University (CNU), South Korea as a postdoc and researched on materials for solid state hydrogen storage technology for three years (2010-2013). In 2014, he joined Heterogeneous Catalysis and In Situ/Operando Spectroscopy Laboratory at ICIQ, Spain as a Marie Curie Fellow (under COFUND program) for 2 years and worked on electrocatalysts for PEM based water electrolysis technology. Currently, he is in the process to join Chemical Engineering Department of University of Southern Denmark (SDU), Denmark as a postdoc where he is expected work on materials for PEM based fuel cells.

His research interest and experience are in development of materials for electrochemical energy conversion and/or storage applications using a variety of chemical synthesis routes. Apart from his main interest in synthesis and design of advanced materials, he also has some interests in automation and test-rig-hardware designing using LabVIEW® and SolidWorks® software packages, respectively.



Muralidhar G. Chourashiya and Atsushi Urakawa. Solution combustion synthesis of highly dispersible and dispersed iridium oxide as an anode catalyst in PEM water electrolysis. J. Mater. Chem. A, 2017, 5, 4774–4778.
