Microsystem Technologies, April 2014, Volume 20, Issue 4-5.
Michael Schneider, Achim Bittner, Ulrich Schmid.
Institute of Sensor and Actuator Systems, Vienna University of Technology, Floragasse 7, 1040, Vienna, Austria.
Abstract
In MEMS (micro electromechanical system) devices, piezoelectric aluminum nitride (AlN) thin films are commonly used as functional material for sensing and actuating purposes. Additionally, AlN features excellent dielectric properties as well as a high chemical and thermal stability, making it also a good choice for passivation purposes for microelectronic devices. With those aspects and current trends towards minimization in mind, the dielectric reliability of thin AlN films is of utmost importance for the realization of advanced device concepts. In this study, we present results on the transversal dielectric strength of 100 nm AlN thin films deposited by dc magnetron sputtering. The dielectric strength is measured using a time-zero approach, using a fast voltage ramp to stress the film up to the point of breakdown. The measurements are performed at different device temperatures. In order to achieve statistical significance, at least 12 measurements are performed for each environment parameter set and the results are analyzed using the Weibull approach. Basically, lower breakdown fields are observed with increasing temperatures up to 300 °C with a characteristic breakdown field strength E 0 following the relationshipE0−−−√∝Tas reported in literature for similar measurements performed at silicon nitride thin films. From the intersection of this linear behavior, the Poole–Frenkel (PF) barrier height ϕ B is determined to 0.54 eV, which is reasonable for AlN thin films. The slope of this relation is similar to values reported for silicon nitride thin films. This allows an estimation of the breakdown field at higher temperatures by extrapolation. Leakage current measurements show a dominant PF type conduction mechanism, verifying the applicability ofE0−−−√∝T. No breakdown occurs in negative field direction, which is attributed to the metal–insulator–semiconductor configuration of the sample and hence, the presence of a depletion layer forming in the n-doped silicon and dominating the leakage current behavior.
